Micro SD Card Connector Push-Push Height 1.80mm
Micro SD Card Connector Push-Push Height 1.80mm
| Categories | Micro SD 3.0 card connector |
|---|---|
| Brand | Moarconn Card Connector Manufacturer |
| Model | Micro SD Card Connector (MC180-T6230-01-W) (5025700893) |
| Product Height | 1.80mm |
| Usable Memory Card | Micro SD 3.0 memory card / TF memory card |
| Base Material | LCP |
| Terminals Material | Phosphorous Bronze |
| Shell Material | Stainless Steel |
| Terms of Payment | L/C, D/A, D/P, Western Union |
| Download |  |
| Update Time | Jun 29,2025 |
Detail Information
Learn about 1.80mm Micro SD Card Connector
Micro SD Memory Card Connector
1.10mm Pitch Micro SD Memory Card Connector,Top Mount SMT Type,Push-Push Structure,1.80mm Height
Advantage：
1. Push-push structure desigin,easily insert or extract Micro SD cars.
2. Stronger machine structure design,support durability of 5000 cycles.
3. Reliable detection switch pins,support ho-plug function.
4. Slope-shaped terminals, prevent terminals damage when the card is inserted and extracted.
Understand the Parameters of the 1.80mm Micro SD Card Connector
|
Technical Parameters
|
||
|
Rating Current:
|
0.5 A
|
|
|
Rating Voltage:
|
500 V
|
|
|
Contact Resistance:
|
100 mΩ
|
|
|
Insulation Resistance:
|
1000 MΩ
|
|
Useful Life: | 5000 cycles | |
|
Additional Parameters
|
||
|
Transmission Rate:
|
104 Mb/s
|
|
|
Number of pins:
|
8
|
|
|
Number of interfaces:
|
1
|
|
|
Features:
|
Smart/Ultrathin
|
|
Used for: | Monitoring Equipments,Industrial Automation,Drive Recorders,Unmanned Aerial Vehicle | |
Download
Detail Drawing of Height 1.80mm Micro SD Card Connector
