Micro SIM Card Connector Push-Pull Height 1.40mm

Micro SIM Card Connector Push-Pull Height 1.40mm
Share
CategoriesMicro SIM Card Connector
BrandMoarconn Card Connector Manufacturer
Product SpecificationsMicro SIM Card Connector (MS140-T5255-01-W) (787270001)
Product Height1.40mm
Usable Memory CardMicro SIM card
Base MaterialLCP
Terminals MaterialPhosphorous Bronze
Shell MaterialStainless Steel
Terms of PaymentL/C, D/A, D/P, Western Union
DownloadDownload pdf
Detail Information
Micro SIM card connector · Push-pull · Top mount

1.40mm Micro SIM card connector
Stable reads, reliable insertion

A 2.54mm pitch, 6-pin Micro SIM card connector in a top mount, push-pull design.

  • 1.40mm mounted height
  • 2.54mm terminal pitch
  • 6 pins
  • 10,000 cycles

Engineer reply within 1 working day · RoHS compliant · Custom options available

MS140-T5255-01
1.40mm height
MS140-T5255-01 · in stock for sampling
Hot-plugcard detect
1.40mmMounted height
10,000Insertion cycles
-45~80°COperating range
Start from the failure

A card connector is invisible — until it fails

Connector failures are rarely dramatic. They are a few milliohms of drift, a lifted pad, a card that reads intermittently in a hot car.

01 / MECHANISM

The more mechanism, the more failure points

Push-pull has no ejector — fewer parts, lower cost, and nothing to jam or wear out. The card is held by the shell and pulled straight out.

No ejector
02 / SIGNAL INTEGRITY

Data drops at speed, card not detected

Gold-plated terminals (≥0.025 µm) hold contact resistance to ≤30 mΩ with tight coplanarity control, keeping high-speed signals stable through humidity and thermal cycling.

Contact integrity
03 / REFLOW RELIABILITY

Reflow warps the insulator, pads lift

An LCP insulator takes lead-free reflow without deformation; the stainless-steel shell keeps the frame flat; terminals are coplanarity-controlled to ±0.05 mm.

SMT yield
04 / FIELD FAILURE

Card detection fails after a few insertions

A reliable detect switch guarantees card detection, backed by the retention structure, for 10,000 insertion cycles.

Card detection
Specifications

Every parameter, translated into a design decision

A datasheet lists values. A specification explains what each value controls. Final tolerances, plating thickness and acceptance criteria are confirmed on the 2D drawing and datasheet.

Mechanical

Mounting type
Top mount
Mounted height
1.40mm
Terminal pitch
2.54mm
Number of pins
6
Mechanism
Push-pull (no ejector)
Terminal coplanarity
±0.05 mm

Electrical

Rated current
0.5 A
Rated voltage
500 V
Contact resistance
≤30 mΩ
Insulation resistance
1,000 MΩ
Transfer rate
Low-speed signal
Durability
10,000 cycles

Materials & plating

Insulator
LCP
Terminals
Phosphorous Bronze · gold ≥0.025 µm
Shell
Stainless Steel
Process
Lead-free reflow compatible
Card type
Micro SIM card

Environment & ordering

Operating temperature
-45 ~ 80°C
RoHS
Compliant
Part number
MS140-T5255-01
Sampling lead time
7 days
Sample policy
Free samples
Inside the connector

Four decisions that keep the card reading

Every structural decision keeps the card reading and held in place.

MS140-T5255-01
MS140-T5255-01 — stainless shell, LCP insulator, gold-plated terminals.
MS140-T5255-01
Top mount, design, 1.40mm mounted height.
01
Push-pull mechanismNo ejector mechanism; the card is held by the stainless shell — push in, pull out. Fewer parts, nothing to jam.
02
Gold-plated phosphor bronze terminalsGold resists oxidation; phosphor bronze keeps normal force over thousands of insertions, holding contact resistance to ≤30 mΩ.
03
LCP insulatorDimensional stability through lead-free reflow, so pin position and coplanarity survive the oven — not just the drawing.
04
Stainless-steel shellHolds the card under drop and vibration, shields the contact field, and keeps the frame flat during assembly.
Selection matrix

Same card, multiple mechanical answers

Same card, same interface — the family offers different height and mechanism combinations. Most mistakes are the right connector in the wrong stack-up.

ModelHeightMechanismMountingChoose it when
MS125-T1161-211.25mmPush-pushTop mountPush-push
MS150-T1130-011.50mmTrayTop mountTray
MS180-T1151-011.80mmTrayTop mountTray
MS150-T1120-021.50mmHingeTop mountHinge
MS142-T6131-011.42mmPush-pushTop mountPush-push
MS150-T5200-011.50mmHingeTop mountHinge
MS140-T5255-01This page1.40mmPush-pullTop mountPush-pull
MS135-T5250-011.35mmPush-pullTop mountPush-pull
MS145-T1250-011.45mmPush-pullTop mountPush-pull
MS180-T1151-011.80mmTrayTop mountTray
SM150-T1150-111.50mmHingeTop mountHinge
MS135-T1250-121.35mmPush-pushTop mountPush-push
Applications

Built for products that get carried, dropped and used daily

Wherever the card is a user-accessible medium, retention and contact stability matter more than price.

Phones & tabletsThe SIM socket carries voice and data — stable contact, reliable insertion.
IoT modules2G/4G/NB-IoT modules use the SIM socket for cellular connectivity.
TrackersSIM connectivity for GPS trackers and asset location.
Industrial routersIndustrial-grade SIM sockets that hold connection under vibration and wide temperature.
Before you ask

Frequently asked questions

What is the difference between Mini / Micro / Nano SIM sockets?

Card size: Mini SIM is largest, Nano SIM smallest. Socket and tray dimensions follow suit, so the choice must match your device slot; the three are not interchangeable.

Does the SIM socket support hot-plug?

Most SIM sockets support hot-plug with a card-detect pin, so the device recognizes the card immediately. Confirm in the datasheet.

Is it reflow compatible?

Yes. SMT sockets use an LCP insulator and coplanarity-controlled terminals for standard lead-free reflow; the exact profile is in the datasheet and drawing.

Can you cross-reference an imported brand?

Send the part number and drawing. We compare pad layout, height, pitch and retention, then confirm drop-in or layout-change before sampling.

What is the minimum order and lead time?

Samples are free, sampling takes 7 days, and volume production is 7–15 days. MOQ and lead time are confirmed with the quotation; zero-MOQ trial runs are available.

Send your stack-up. Get a drawing, a sample and a straight answer.

Tell us the product thickness, card type, annual volume and the part you are replacing (if any). An engineer replies within one working day with the right model, the drawing you need, and what we would change in your layout — if anything.

1Send requirements
2Drawing + sample
3Approve & produce
Request a quote & sample sales@moarconn.com

Mention part number MS140-T5255-01 for the fastest reply.
